Chevy SB 383ci Crate Engine
BluePrint Engines : BP38318CTF1
Nº d'article: BPEBP38318CTF1
Crate Engine Long Block
New GM 350 c.i.d. 4-Bolt 2-Piece Rear Main Seal
Horsepower: 315
Torque: 381
Compression: 9.0:1
Displacement: 350 c.i.d.
(4.000" bore x 3.480" stroke)
Crankshaft: Cast Iron
Pistons: Cast Aluminum
Camshaft: Performer #E
- Air Cleaner Included: No
- Block Description: New BluePrint block, 1 piece rear main sale, 4 bolt main, passenger side dipstick
- Cam: Roller, .528 Intake .536 Exhaust, 221 Intake / 226 Exhaust duration @ .050 - 110 degree lobe separation
- Carburetor/ Fuel Injection Included: No
- Compression Ratio: 10.0:1
- Country of Origin: USA
- Crankshaft Vendor: BluePrint or Scat
- Cylinder Head Vendor: BluePrint, H8002K
- Cylinder Heads: Aluminum, 64cc chamber
- Cylinder Heads Included: Yes
- Description: Base Dressed 383 with Aluminum Heads, Roller Cam and Fuel Injection
- Dimensions: 30"Wx27"Lx38"H
- Distributor Included: No
- Distributor Vendor: BluePrint or MSD
- Engine Balance: External - Front External - Rear
- Firing Order: 1,8,4,3,6,5,7,2
- Flexplate/ Flywheel Included: No
- Fuel Delivery Type: Fuel Injected
- Fuel Delivery Vendor: Holley Sniper EFI
- Harmonic Balancer Included: No
- HP: 438
- Intake Manifold Included: Yes
- Intake Manifold Type: Dual plane, satin aluminum
- Intake Manifold Vendor: Edelbrock or BluePrint
- Oil Pan Included: Yes
- Pistons: Hypereutectic
- Quantity: EA
- Rear Main Seal Style: 1 pc
- Recommended Flywheel / Flexplate: Late 350 Weighted
- Recommended Harmonic Balancer: 400 ci weighed, 8" diameter
- Recommended Octane Fuel: 91 Octane
- Recommended Spark Plug Gap: .045"
- Recommended Spark Plugs: Champion 792
- Recommended Stall Converter: 2000-2400 rpm
- Rotating Assembly: Cast Crank - 3.75" stroke and 5.7" Rods
- Shipping Weight: 460
- Spark Plug Wires Included: No
- Spark Plugs Included: No
- Timing Cover Included: Yes
- Timing Requirements: Initial timing - 10-16° and Total timing 32-34°
- TQ: 443
- Valve Covers Included: Yes
- Water Pump Included: No
- Make: GM
- HP: 436 HP
- CID: 383 CID
